Where to use:
Bonding primer for overlays and repair materials to hardened concrete.How to apply:
Spray, roller, or brush applied. Additional InformationMinimize InformationPerformance Characteristics
- Single component No mixing, no waste.
- Long open time Apply up to 72 hours before placing covering material.
- Color trigger Pink when applied, turns orange when ready for covering material – about 30 minutes.
- Alkali trigger Alkalinity of cement causes material to react.
- Breathability Water vapor permeable.
- Non re-emulsifying Once cured will not be affected by water.
- Environmentally friendly Water based, low odor, non-flammable.
- Easy to use Spray with low pressure or airless sprayer.
Surface Preparation
- Remove loose and deteriorated material, laitance, dirt, dust, oil and any surface contaminants that will inhibit proper penetration.
- Follow the specific surface preparation instruction for the Conproco material to be used.
- When placing fresh concrete expose aggregate of existing substrate a minimum of 1/8 inch (CSP 6). Refer to ICRI Surface Preparation Guide 03732 for information about Concrete Surface Profile (CSP).
- Protect adjacent areas from overspray.
Priming
- Conpro Primer is a priming treatment that is applied in a thin, uniform application.
Mixing
- Stir or shake container
Application
- Spray, roll, or brush Conpro Primer in a thin, uniform application.
- Do not allow Conpro Primer to form a surface film. It is critical to avoid excessive Conpro Primer thickness as this will result in a cohesive adhesion failure and delamination. On scarified horizontal applications, broom Conpro Primer immediately after spraying to avoid ponding. Conpro Primer is formulated to penetrate into the substrate.
- For roller applications use a 3/8 – 1/2 inch synthetic nap roller depending on texture of substrate.
- For spray applications use a low pressure or airless sprayer.
- Apply to all surfaces to receive covering material including the edges perpendicular to the repair zone.
- The material is pink when applied.
- The material will turn orange when dry – approximately 30 minutes @ 70°F and 50° RH.
- Apply covering material when Conpro Primer is orange.
- Install covering material within 72 hours.
- Re-apply Conpro Primer if more than 72 hours passes without placing covering material.
Curing
- No curing is required.
Clean Up
- Clean tools and equipment with water.
Coverage/Yield
- 150 – 200 ft.2/gal. depending on porosity of treated surface.
- Apply a test sample to determine actual coverage.
Product Handling
- Packaging 1 and 5 gallon containers
- Shelf Life 18 months in unopened containers.
- Storage Protect from freezing. Transport and store in cool, clean, dry conditions in unopened containers. High temperature will reduce shelf life.
Limitations
- Do not apply unless substrate and ambient temperature can be maintained at a minimum of 40°F for 8 hours. Refer to ACI Cold Weather Application Guidelines.
- Do not use Conpro Primer in lieu of proper surface preparation. Refer to ICRI Surface Preparation Guidelines for complete information.
- Contact Conproco for information on using Conpro Primer for DOT applications.
- Protect adjacent surfaces, Conpro Primer is pigmented and will discolor porous surfaces.
- Do not apply to frozen substrates.
- Do not apply on painted surfaces.
- Use caution when spraying in windy conditions.
Health and Safety
- Product is alkaline.
- Do not ingest.
- Avoid contact with eyes.
- Refer to Safety Data Sheet (SDS) for additional information.
First Aid
- In case of skin contact, wash thoroughly with soap and water.
- In case of eye contact, flush immediately with a high volume of water for at least 15 minutes and contact a medical professional.
- For respiratory problems, remove person to fresh air.
- If respiratory difficulty persists, contact a medical professional.
Disposal
- Dispose of material in accordance with local, state and federal regulations.
- Technical Data
- Data Bulletin
- CSI Spec
- Competition
- Curing
- Pump & Spray
- FAQs
- Safety Data Sheet
Physical state and appearance | Â | Orange, milky liquid. |
---|---|---|
Base | Â | Aqueous |
Polymer | Â | 100% acrylic |
pH | Â | >9.0 |
Percent solids by weight | Â | 31% |
Flash point | ASTM D56 | >200°F Seta cc |
Viscosity | ASTM D562 | 50 KU – paint paddle |
Volatile organic content – VOC | ASTM D3960 | 1 gm./liter |
Density of liquid coatings | ASTM D1475 | 8.4 lbs./gal. |
Resistance to chemicals | ASTM D1308 | NaOH solution - excellent |
Standards for latex bonding primers | ASTM C1059 | Type 11 – exterior use |
Mandrel bend | ASTM C522 | No cracking over 1 inch material |
Slant shear bond strength | ASTM C882 | 1850 psi – air cure |
Heat stability | ASTM C932 | Pass – 30 days @ 140°F |
 |  | 3 days          7 Days          14 Days |
Tensile bond strength | ASTM C932 | Â |
    100% cohesive in concrete patch – psi |  | 190 |
    80% cohesive in concrete patch - psi |  |                    410 |
    80% cohesive in concrete patch – psi |  |                                               525 |
Conproco | Â | BASF | Edison | Euclid / Tamms | Mapei | Sika | USCP |
---|---|---|---|---|---|---|---|
 | Lapidoltih | System 95W | Hornolith | None | None | None | |
Corrosion Inhibitors | Master Emaco P124; Zincrich Primer | System 49 CPBA | Dural Prep A.C. | Mapefer 1K | Armatec 110 | HP Bondit lll | |
Bonding Primers | Master Emaco P130; Master Protect P8100 AP; Master Protect P200 | None | Dural Prep A.C. | Planibond 3C | Armatec 110 | None |
Cementitous Products
Product | Minimum Temperature | Minimum to 55° F | 55°F – 70° F | 70° F and above | Minimum Time to Coat |
---|---|---|---|---|---|
ISR CM | 40° | 12 Hours | 4 Hours | 2 Hours | 3 to 5 days depending on temperature |
ISR VO | 40° | 12 Hours | 4 Hours | 2 Hours | 3 to 5 days depending on temperature |
ISR AG | 40° | 12 Hours | 4 Hours | 2 Hours | 3 to 5 days depending on temperature |
Conpro Set | 40° | 12 Hours | 4 Hours | 2 Hours | 3 to 5 days depending on temperature |
Quick Shot | 40° | 8 Hours | 2 Hours | 1 Hour | 3 to 5 days depending on temperature |
Forment (remove forms) | 40° | 72 Hours | 48 Hours | 24 Hours | 3 to 5 days depending on temperature |
Gun Shot LPS | 40° | 12 Hours | 4 Hours | 2 Hours | 3 to 5 days depending on temperature |
Injection Grout (remove clay) | 40° | 24 Hours | 24 Hours | 24 Hours | 3 to 5 days depending on temperature |
One Shot 2C | 45° | 24 Hours | 12 Hours | 6 Hours | 3 to 5 days depending on temperature |
Matrix | 40° | 12 Hours | 4 Hours | 2 Hours | 3 to 5 days depending on temperature |
Matrix TR | 50° | 12 Hours | 4 Hours | 2 Hours | 3 to 5 days depending on temperature |
Repoint | 40° | 12 Hours | 4 Hours | 2 Hours | 3 to 5 days depending on temperature |
Plastermix | 40° | 12 Hours | 4 Hours | 2 Hours | 3 to 5 days depending on temperature |
Structural Skin | 40° | 12 Hours | 4 Hours | 2 Hours | 3 to 5 days depending on temperature |
Conpro One Coat | 40° | 12 Hours | 4 Hours | 2 Hours | 3 to 5 days depending on temperature |
Conpro Stucco | 40° | 12 Hours | 4 Hours | 2 Hours | 3 to 5 days depending on temperature |
Foundation Coat | 40° | 12 Hours | 4 Hours | 2 Hours | 3 to 5 days depending on temperature |
Super Seal | 40° | 12 Hours | 4 Hours | 2 Hours | 3 to 5 days depending on temperature |
Liquid Products
Product | Minimum Temperature | Minimum to 55° F | 55°F – 70° F | 70° F and above | Minimum Time to Coat |
---|---|---|---|---|---|
Conpro Start | 40° | 18 Hours | 12 Hours | 6 Hours | Refer to temperature |
ECB | 40° | 8 Hours | 1 Hour | 30 Minutes | Dry to touch |
Primer | 40° | 8 Hours | 1 Hour | 30 Minutes | Color change to orange |
Shield MX | 40° | 24 Hours | 18 Hours | 12 Hours | Dry to touch |
M3P & M3P-X | 45° | 24 Hours | 18 Hours | 12 Hours | Dry to touch |
M3P Overcoat | 45° | 24 Hours | 18 Hours | 12 Hours | Dry to touch |
Conpro Lastic | 45° | 24 Hours | 18 Hours | 12 Hours | Dry to touch |
Color Coat | 45° | 24 Hours | 18 Hours | 12 Hours | Dry to touch |
Super Color Stain | 45° | 24 Hours | 18 Hours | 12 Hours | Dry to touch |
Elastideck | 45° | 24 Hours | 18 Hours | 12 Hours | Dry to touch |
Terra Color | 45° | 24 Hours | 18 Hours | 12 Hours | Dry to touch |
Terracotta Finish | 45° | 24 Hours | 18 Hours | 12 Hours | Dry to touch |
For Cement Based Materials
The gallons per minute volume of a rotor/stator pump is determined by the pump size (i.e. size 6 has a larger capacity than size 3). The pressure capacity of a pump is determined by the number of stages. Thicker materials and longer distances require higher pressure.Â
 | Marshalltown | Hy-Flex | Quickspray | ChemGrout | Reed |
---|---|---|---|---|---|
Forment® | – | X | X | X | X |
Gun Shot LPS | – | X | X | X | – |
Plastermix | X | X | X | X | – |
ISR AG | – | – | – | – | X |
Conpro One Shot 2C | – | X | X | X | – |
Elastideck | X | X | X | X | – |
Structural Skin® | – | X | X | X | – |
Conpro One Coat | – | X | X | X | – |
Conpro Stucco | X | X | X | X | – |
Foundation Coat | – | X | X | X | – |
Conpro Super Seal | X | X | X | X | – |
Manufacturer Contact Information
For Liquids and Coatings
The capacity of airless spray equipment is determined by the tip size. Given the proper tip size, the manufacturer of the equipment will be able to recommend specific equipment.
 | R.E. Chapin MFG | Titan Tool Inc. | Binks | Graco Inc. |
---|---|---|---|---|
Conpro Start | X | X | – | – |
ECB | – | – | – | X |
Conpro Primer | X | X | – | – |
Conpro Shield MX | X | – | – | – |
M3P | – | – | X | – |
M3P-X | X | X | – | – |
Conpro Lastic | – | – | – | X |
Color Coat | – | – | X | – |
Super Color Stain | – | – | X | – |
Manufacturer Contact Information
Horizontal areas that are resurfaced are often exposed to the elements, particularly sun. It can be difficult to maintain an SSD condition which can result in delamination. Primer has a 72 hour open time, eliminating the dry surface problem.     Â
Bonding primers are also beneficial when site conditions make SSD (Saturated Surface Dry) of vertical repairs difficult.
